- FEATURES
- TECHNICAL SPECIFICATIONS
AVAILABLE IN
- 700 VA / 12V
- 900 VA / 12V
- 1100 VA / 12V
- 2200 VA / 24V
GALAXY HOME UPS FEATURES
- Pure Sine Wave output
- Micro controller based technology using MOSFET
- Automatic low battery cut-off
- Overload sensing and short circuit protection
- PWM controlled efficient fast charging
- Fuzzy logic system
- Battery level auto sense smart charger
- Automatic battery level management
- Serve dual inverter as well as UPS
- Graphical Display
TECHNICAL SPECIFICATIONS
| Specification | Details |
|---|---|
| Mains AC low cut off voltage | Inverter Mode : 120 VAC I UPS mode 180 VAC ( +- 5 %) |
| Mains Ac High cut voltage | Inverter Mode : 285 VAC I UPS mode 265 VAC ( +- 5 %) |
| Output voltage with full load | Inverter Mode : 220 VAC I UPS mode 220 VAC ( +- 5 %) |
| Battery low voltage | Inverter Mode : 10.5 V I UPS mode 10.5 V ( +- 2 %) |
| Battery charging | PWM controlled efficient fast charging |
| Battery charging mains voltage range | Inverter Mode : 120 V to 280 V I UPS mode 180 V to 265 V |
| Maximum charging current | LB - 8 A +- 1 A |
| Maximum charging current | Sb - 10A +- 1 A |
| Trickle charging current | 0.5 A + - 0.3 A |
| Overload | 100 + - 3 % ( With auto reset function ) |
| Short circuit protection | > 300 % Load ( With auto reset function ) |
